Additional functions 8.8
8
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
259
Group name, ID no. Number Index Meaning
9 Tool no. Maximum tool age TIME1
10 Tool no. Maximum tool age TIME2
11 Tool no. Current tool age CUR. TIME
12 Tool no. PLC status
13 Tool no. Maximum tooth length LCUTS
14 Tool no. Maximum plunge angle ANGLE
15 Tool no. TT: Number of tool teeth CUT
16 Tool no. TT: Wear tolerance for length LTOL
17 Tool no. TT: Wear tolerance for radius RTOL
18 Tool no. TT: Rotational direction DIRECT (0=positive/–
1=negative)
19 Tool no. TT: Offset in plane R-OFFS
20 Tool no. TT: Offset in length L-OFFS
21 Tool no. TT: Break tolerance for length LBREAK
22 Tool no. TT: Break tolerance for radius RBREAK
28 Tool no. Maximum rpm NMAX
32 Tool no. Point angle TANGLE
34 Tool no. LIFTOFF allowed (0= No, 1= Yes)
35 Tool no. Wear tolerance for radius R2TOL
37 Tool no. Corresponding line in the touch-probe table
38 Tool no. Timestamp of last use
Pocket table data, 51 1 Pocket number Tool number
2 Pocket number Special tool: 0=No, 1=Yes
3 Pocket number Fixed pocket: 0=No, 1=Yes
4 Pocket number Locked pocket: 0=No, 1=Yes
5 Pocket number PLC status
Pocket number of a tool in
the tool-pocket table, 52 1 Tool no. Pocket number
2 Tool no. Tool magazine number
