Graphically testing the first part

1.4

1

TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013

53

Choosing the program you want to test

Press the PGM MGT key: The TNC opens the file
manager

Press the LAST FILES soft key: The TNC opens a
pop-up window with the most recently selected
files

Use the arrow keys to select the program that you
want to test. Load with the ENT key

Further information on this topic

Selecting a program: See "Working with the file manager",
page 98

Selecting the screen layout and the view

Press the key for selecting the screen layout. The
TNC shows all available alternatives in the soft-key
row

Press the PROGRAM + GRAPHICS soft key: In
the left half of the screen the TNC shows the
program; in the right half it shows the workpiece
blank

Select the desired view via soft key

Plan view

Projection in three planes

3-D view

Further information on this topic

Graphic functions: See "Graphics ", page 438

Running a test run: See "Test Run", page 449
