Programming: Q Parameters
8.8 Additional functions
8
262
TNC 320 | User's Manual HEIDENHAIN Conversational Programming | 5/2013
Group name, ID no. Number Index Meaning
Traverse range, 230 2 1 to 9 Negative software limit switch in axes 1 to 9
3 1 to 9 Positive software limit switch in axes 1 to 9
5 - Software limit switch on or off:
0 = on, 1 = off
Nominal position in the REF
system, 240 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
Current position in the
active coordinate system,
270 1 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7 U axis
8 V axis
9 W axis
