SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-47
5.6.9 FUNCTION SELECT:UTILITY:MOD OPTIONS
REV EMULATION
CURRENT VERSION
Use this menu to select the emulation mode of a previous functional revision. Revision
emulation allows the user interfaces (either front panel or remote) to emulate a previous
version of software. Upon entry, the current version is displayed.
1 Press a arrow key to select the FUNCTIONAL versions.
2 Press [ENTER] to execute the change.
Note: The Utility menu numbers increase with each software version change.
MOD OPTIONS
-++
This menu displays the modulator options listed below. If an option is not installed, the “-
“ (minus) symbol is displayed to the right of the option. If the option is installed, the “+“
(plus) symbol is displayed to the right of the option.
• OEM LCD (- or +)
• 16QAM (- or +)
• 8PSK (- or +)
- = Not Installed
+ = Installed
MODEM SERIAL #
012345678
This is a status-only display of the modulator serial number.
CONFIGURATION
CODE – MOD
Use this window to execute the Comtech EF Data-supplied “FAST” code. On entry, the
current configuration code is displayed with the flashing cursor on the first character.
