SDM-2020 Satellite Modulator
Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-19
Parameter Type
Command/Status/
Response
Description of Arguments
Comments
Modulator Stored Faults
Command:
Response:
MM/DD/YYYY'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
IF_xxx'cr'
CONF_xxx'cr''lf']
Module (OK/FLT)
IF Synthesizer (OK/FLT)
Data Clock Synthesizer (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
AGC Level (OK/FLT)
IF Module Fault (OK/FLT)
Configuration (OK/FLT)
Interface Transmit Side
Stored Faults
Command:
Response:
MM/DD/YYYY'cr'
FSYN_xxx'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
FIFO_xxx'cr'
INT_xxx'cr'
DF_xxx'cr''lf']
VSYN_xxx'cr''lf']
Frame Sync Lock (OK/FLT)
Transmit Data (OK/FLT)
Transmit Synthesizer PLL Lock
(OK/FLT)
Transmit Clock Activity (OK/FL)
Transmit FIFO (OK/FLT)
Interface Module (OK/FLT)
Data Format (OK/FLT)
Video Sync (OK/FLT)
Common Equipment
Stored Faults
Command:
Response:
MM/DD/YYYY'cr'
M&C_xxx'cr'
BAT_xxx'cr'
+5_xxx'cr'
+12_xxx'cr'
-12_xxx'cr''lf']
Monitor & Control Module (OK/FLT)
Battery/Clock (OK/FLT)
+5V Power Supply (OK/FLT)
+12V Power Supply (OK/FLT)
-12V Power Supply (OK/FLT)
