SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-9
A.2.2.1 RS-422 I
NTERFACE
Parameter
Type
Command/
Status/
Response Description of Arguments Comments
BMC
Parameters
23 to 40 23
24
25
26
27
28
29 thru 40
Interface Select Mode
(ref. 'ISEL_' command).
Interface Clock Mode
(ref. ‘ICLK_' command).
RTS TX-IF Control Mode
(ref ‘RTSM_' command).
RTS State Control
(ref 'RTSS_' command).
CTS State Control
(ref ‘CTSS_' command).
DM State Control
(ref. ‘DM_’command).
Reserved p23 = n, where n = '0' (DVB, 1 =530)
p24 = n, where n = '0' (Serial), '1' (Parallel).
p25 = n, where n = '0' (Off), '1' (On).
p26 = n, where n = '0' (Normal), '1' (Invert).
p27 = n, where n = '0' (Normal), '1' (Invert).
P28 = n, where n = ‘0’(Normal), ‘1’ (Invert)
A.2.2.2 LVDS I
NTERFACE
Parameter
Type
Command/
Status/
Response Description of Arguments Comments
BMC
Parameters
23 to 40 23
24 thru 40
Interface Clock Mode
(ref. ‘ICLK_' command).
Reserved p23 = n, where n = '0' (Serial), '1' (Parallel).
