Front Panel Operation MN/SDM2020M.IOM
5-35
DTE STATE
NORMAL
This display shows the DTE STATE selection of either NORMAL or INVERTED. Upon
entry, the current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
DCE STATE
NORMAL
This display shows the DCE STATE selection of either NORMAL or INVERTED. Upon
entry, the current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
5.6.8.5 FUNCTION SELECT:UTILITY:G.703
INTERFACE TYPE
G.703
This status-only item displays G.703 or UNKNOWN. No changes can be made from this
menu. Use [
↑] or [↓]to select an interface type and press .
INTRFC LOOP THRU
OFF
This display shows the Interface Loop Thru either in ON or OFF position. Upon entry, the
current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
