SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-29
RTS STATE
NORMAL
This display shows the status of RTS STATE (either NORMAL or INVERT ).
Upon entry, the current status of RTS is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
CTS STATE
NORMAL
This display shows the status of CTS STATE (either NORMAL or INVERT).
Upon entry, the current status of CTS is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
DM STATE
NORMAL
This display shows the status of DM STATE (either NORMAL or INVERT).
Upon entry, the current status of DM STATE is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
