SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-34
Parameter
Type
Command/
Status/
Response Description of Arguments Comments
BCS
Parameters
23 to 32 23
24
25
26-32 DTE TX-IF Control Mode
(ref. 'DTEM_' command).
DTE State Control
(ref “DTES_”command).
DCE State Control
(ref “DCES_”command).
Reserved. p23 = n, where n = '0' (Off), '1' (On).
P24 = n, where n ='0' (Off), '1' (On).
P25 = n, where n = '0' (Off), '1' (On).
A.10 G.703 C
OMMANDS
Parameter
Type
Command/
Status/
Response Description of Arguments Comments
Interface
Loop-back Command:
Response:
Status:
Response: >add/ILB_xxx'cr''lf']
>add/ILB_xxx'cr''lf']
Where: xxx = On or Off.
Interface Loop
Thru Mode Command:
Response:
Status:
Response: >add/ILM_xxx'cr''lf']
>add/ILM_xxx'cr''lf']
Where: xxx = On or Off.
Interface
Coding Format
Transmit Command:
Response:
Status:
Response: >add/ICFT_xxxx'cr''lf']
>add/ICFT_xxxx'cr''lf']
Where: xxxx = AMI, HDB3, B8ZS, or B3ZS.
RTS TX-IF
Control Mode Command:
Response:
Status:
Response: >add/RTSM_xxx'cr''lf']
>add/RTSM_xxx'cr''lf'] Where: xxx = ON or OFF.
This command configures the modem for the RTS
TX-IF control mode. If 'ON' is selected, the TX-IF
output will only be turned on if the incoming RTS
signal is asserted (also the TX-IF output has to be
programmed ON and no major modulator faults
are preset). If 'OFF' is selected, the TX-IF output
will operate normal ignoring the RTS signal.
RTS State
Control Command:
Response:
Status:
Response: >add/RTSS_xxx'cr''lf']
>add/RTSS_xxx'cr''lf'] Where: xxx = ON or OFF.
This command controls the logic of the RTS
signal.
