Comtech EF Data SDM-2020 - Manual (Page 238)

SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
Parameter
Number
Parameter Name
(Command Reference) Description
BCS
Parameters
1 to 33 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Modem Remote/Local mode
Modulator RF Output
(ref. 'RF_' command).
Modulator IF Frequency
(ref. 'MF_' command).
Modulator Rate
(ref. 'MR_' command).
Modulator Rate
(ref. 'ASR_' command).
Modulator Power Offset
(ref. 'MPO_' command).
Modulator Output Power Level
(ref. 'MOP_' command).
Scrambler Enable
(ref. 'SE_' command).
TX Output Power-up Configuration
(ref. 'TXPU_' command).
Carrier Only Mode
(ref. 'COM_' command).
Modulator Type
(ref. 'MT_' command).
Transmit Clock Phase
(ref. 'TCP_' command).
Transmit Data Phase
(ref. 'TDP_' command).
Transmit Data Phase
(ref. 'TDF_' command).
Transmit 2047 Pattern Generator
(ref. 'ISP_' command).
Transmit Clock Phase
(ref. 'SYNC_' command).
DVB Framing Type
(ref. 'TDVB_' command).
Modulator Spectrum Rotation
(ref. 'MSR_' command). p1 = n, where 'n' is '0' (LOCAL) or '1' (REMOTE).
p2 = n, where 'n' is '0' (Off) or '1' (On).
p3 = nnn.nnnn, IF frequency in MHz.
p4 = nnnn_mmm.mmmmmm, code rate/data rate in
Mbps.
p5 = nnnn_mm.mmmmmm, code rate/symbol rate in
Msps.
p6 = snn.n, transmitter power offset level in dBm.
p7 = snn.n, transmitter output power in dBm.
p8 = n, where 'n' is '0' (off) or '1' (on).
p9 = n, where 'n' is '0' (off) or '1' (last).
p10 = n, where 'n' is '0' (Off), '1' (Dual),' 2' (Offset),
or '3' (Center).
p11 = n, where 'n' = '0' (DVB-1) or '1' (DVB-2).
p12 = n, where 'n' is '0' (NRM), '1' (INV), or '2'.
p13 = n, where 'n' is '0' (NRM) or '1' (INV).
p14 = n, where 'n' is '0' (None), '1' (Data stable), or
'2' (AIS).
p15 = n, where 'n' is '0' (off) or '1' (on).
p16 = n, where 'n' is '0' (EXT), '1' (DATA), or '2'
(AUTO).
p17 = n, where n = '1' (188), '2' (NONE), or '3' (204).
p18 = n, where 'n' is '0' (NRM) or '1' (INV).
A-21
