SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
Parameter
Command/
Status/ Description
Type Response of Arguments Comments
MCP
Command
Config. Command:
Response:
>add/MCP_'cr'
ISEL_xxxxxx'cr'
ICLK_xxx'cr'
TDVB_xxxx'cr'
MF_nnn.nnnn'cr'
MR_nnnn_mmm.mmmmmm'cr'
MPO_snn.n'cr'
MOP_snn.n'cr'
SE_xxx'cr'
TCP_xxx'cr'
TDP_xxxx'cr'
TDF_xxxx'cr'
ISP_xxx'cr'
SYNC_xxxx'cr'
MSR_xxx'cr'
MT_xxxx'cr'
TXPU_xxxxx'cr'
COM_xxxxxx'cr'
RTSM_xxx'cr'
RTSS_xxx'cr'
CTSS_xxx'cr'
DMS_xxx'cr'
TCAA_xxxx'cr'
RF_xxx'cr''lf']
Interface Select
Interface Mode
DVB Framing Type
Modulator Frequency
Modulator Rate
Modulator Power Offset
Modulator Output Power
Scrambler Enable (ON/OFF)
Transmit Clock Phase
Transmit Data Phase
Transmit Data Fault
Transmit 2047 Pattern Generator
Transmit Sync Select
Modulator Spectrum Rotation
Modulator Type
Transmit IF Output Power-up Configuration
Carrier Only Mode
RTS Mode Control
RTS State Control
CTS State Control
DMS State Control
TX Clock Activity Action
RF Output (ON/OFF)
ICS
Command
Config. Command:
Response:
>add/ICS_'cr'
TCP_xxx'cr'
TDP_xxxx'cr'
ISP_xxx'cr'
SYNC_xxxx'cr'
TDF_xxxx'cr'
TDVB_xxxx'cr'
INID_xxxxxxxxx'cr'
ISEL_xxxxxx'cr'
ICLK_xxx'cr'
RTSM_xxx'cr'
RTSS_xxx'cr'
CTSS_xxx'cr'
DMS_xxx'cr'
TCAA_xxxxx'cr''lf']
Transmit Clock Phase
Transmit Data Phase
Transmit 2047 Pattern Generator
Transmit Sync Select
Transmit Data Fault
DVB Framing Type
Interface Identification
Interface Select
Interface Mode
RTS Mode Control
RTS State Control
CTS State Control
DM State Control
TX Clock Activity Action
A-27
