SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
A.13 O
RIGINAL
E
QUIPMENT
M
ANUFACTURER
L
IQUID
C
RYSTAL
D
ISPLAY
O
PTION
The OEM LCD option permits the user to specify three pieces of information in the
equipment.
Lines 1 and 2 of the LCD display.
The identification of the unit when the remote port is interrogated for “equipment
type.”
If the manufacturer is to program this data into the equipment prior to delivery, the user
must specify the three strings. The manufacturer requires the string information ( as
specified in Column 4). The instructions for programming of the data via the equipment's
remote port is as follows:
Parameter
Command/
Response Remote Specification String Information
Program
OEM
String 1
(Note 1) Command:
Response:
Status:
Response:
>add/OES1_xxxxxxxxxxxxxxxx'cr''If']
>add/OES1_xxxxxxxxxxxxxxxx'cr''If'] Where : xxxxxxxxxxxxxxxx =
16-character string to be displayed
on Line 1 of the modem LCD.
Program
OEM
String 2
(Notes 1
and 2) Command:
Response:
Status:
Response:
>add/OES2_xxxxxxxxxxxxxxxx'cr''If']
>add/OES2_xxxxxxxxxxxxxxxx'cr''If'] Where : xxxxxxxxxxxxxxxx =
16-character string to be displayed
on Line 2 of the modem LCD.
Program
OEM
String 3
(Note 3) Command:
Response:
Status:
Response: >add/OES3_xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx'cr''lf']
>add/OES3_xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx'cr''If'] Where :
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
= 32-character string returned
when the ET_ (equipment type)
command is executed via the
remote port.
Notes:
1. A space in the display is created by the exponent character (^) in the string.
2. If a single question mark (?) is used as the OEM string 2, then the current version of the
M&C firmware is displayed. This is the usual entry.
3. Spaces are not allowed in OEM string 3. Use an underscore ( _ ) as a separator between
characters, see example:
Incorrect: xxxx
yyyy
Correct: xxxx_yyyy
4. FAST Upgrade Required
5. The
<add/REM_ command shall be issued.
A-41
