SDM-2020 Satellite Modulator

Revision 7

Front Panel Operation

MN/SDM2020M.IOM

5-27

5.6.8

FUNCTION SELECT:UTILITY:INTERFACE

INTERFACE TYPE

XXXXXXXXXXX

Selections include:

RS-422 LVDS

ASI/RS422 ECL/HSSI

G.703 SMPTE

310

ASI/LVDS UNKNOWN

Use the [

←] [→] arrows to make a selection.

Press .

Additional data interfaces will be added to the menu as they are introduced. If an
interface is not recognized, then UNKNOWN is displayed. In this case, a later version of
firmware may be required to operate with the data interface.
