SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-10
A.2.2.3 ASI/RS-422 I
NTERFACE
Parameter
Type
Command/
Status/
Response Description of Arguments Comments
BCS
Parameters
23 to 40 23
24
25
26
27
28
29
30
31
32
33 to 40 Interface Select Mode
(ref. 'ISEL_' command).
RTS TX-IF Control Mode
(ref. 'RTSM_' command).
RTS State Control
(ref 'RTSS_' command).
CTS State Control
(ref 'CTSS_' command).
DM State Control
(ref 'DMS_' command).
ST State Control
(ref 'ST_' command).
ASI Input Control
(ref 'ASI_' command).
ASI Loop Bandwith Control
(ref ‘ASLB_’command).
Interface Loopback
(ref. ‘ILB_”command).
Interface Loop Thru Control
(ref. ‘ILM_”command).
Reserved p23 = n, where n = '0' (ASI), '1' (RS422).
p24 = n, where n = '0' (Off), '1' (On).
p25 = n, where n = '0' (Normal), '1' (Invert).
p26 = n, where n = '0' (Normal), '1' (Invert).
p27 = n, where n = '0' (Normal), '1' (Invert).
p28 = n, where n = '0' (Normal), '1' (Invert).
p29 = n, where n = 'A' (A-Input), 'B' (B-Input).
p30 = n, where n = '0' (Wide), '1' (Narrow).
p31 = n, where n = ‘0’ (Off), ‘1’ (On).
p32 = n, where n = ‘0’ (Off), ‘1’ (On).
