SDM-2020 Satellite Modulator
Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-40
ICS
Command
Config.
Command:
Response:
TCP_xxx'cr'
TDP_xxxx'cr'
ISP_xxx'cr'
SYNC_xxxx'cr'
TDF_xxxx'cr'
TDVB_xxxx'cr'
INID_xxxxxxxxx'cr'
ISEL_xxxxxx'cr'
ICLK_xxx'cr'
ASI_x'cr'
RTSM_xxx'cr'
RTSS_xxx'cr'
TCAA_xxxxx'cr’
ASLB_xxxxxx’cr’
IJ1_xx’cr’
ASIA_xxxx’’lf’]
Transmit Clock Phase
Transmit Data Phase
Transmit 2047 Pattern Generator
Transmit Sync Select
Transmit Data Fault
DVB Framing Type
Interface Identification
Interface Select
Interface Mode
ASI Input
RTS Mode Control
RTS State Control
TX Clock Activity Action
ASI Loop Bandwidth
Interface Jumper Position #1
ASI Link Mode (MAN/AUTO)
Para
Number
Parameter Name
(Command Reference)
Description
BCS
Parameters
23 to 32
23
24
25
26
27
28
29
30
31
32
Interface Select
(ref. 'ISEL_' command).
RTS TX-IF Control Mode
(ref. 'RTSM_' command).
RTS State Control
(ref 'RTSS_' command).
ASI Input Control
(ref 'ASI_' command).
ASI Loop Bandwidth Control
(ref 'ASLB_' command).
Interface Loopback
Interface Loop Thru
Interface Jumper #1
ASI Link Mode
(ref ‘ASIA_’command)
Reserved.
p23 = n, where n = '0' (ASI), '1' (LVDS).
p24 = n, where n = '0' (Off), '1' (On).
p25 = n, where n = '0' (Normal), '1' (Invert).
p26 = n, where n = '0' (A-Input), '1' (B-Input).
p27 = n, where n = '0' (Wide), '1' (Narrow).
p28 = n, where n = '0' (Off), '1' (On).
p29 = n, where n = '0' (Off), '1' (On).
p30 = n, where n = ‘0’ RX LVDS), ‘1’ (TX LVDS )
p31 = n, where n = ‘0’ (Manual), ‘1’ (Auto)
