SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-41
LVDS STATUS (J7)
RX LVDS
Note: Jumper setting dependent.
This display shows the status of either RX LVDS or TX LVDS. Upon entry, the current
status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
RTS TX-IF CNTRL
OFF
This display shows whether the RTS TX-IF Control is ON or OFF. Upon entry, the
current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
RTS STATE
NORMAL
This display shows the RTS selection of either NORMAL or INVERT. Upon entry, the
current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
