SDM-2020 Satellite Modulator Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-8
BMC
Parameters
1 to 33 Parameter
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 through
22
23 through
40 Parameter Name
(Command Reference)
Modulator Rate Assignment
(ref."AMRV_"command)
Modulator IF Frequency
(ref. 'MF_' command).
Modulator RF Output
(ref. 'RF_' command).
Modulator Output Power Level
(ref. 'MOP_' command).
Modulator Power Offset
(ref. 'MPO_' command).
Carrier Only Mode
(ref. 'COM_' command).
Modulator Spectrum Rotation
(ref. 'MSR_' command).
TX Output Power-up Configuration
(ref. 'TXPU_' command).
Modulator Type
(ref. 'MT_' command).
Scrambler Enable
(ref. 'SE_' command).
Transit Clock Phase
(ref. 'TCP_' command).
Transmit Data Phase
(ref. 'TDP_' command).
Transmit 2047 pattern generator
(ref. 'ISP_' command).
Transmit Sync Select
(ref. 'SYNC_' command).
Transit Data Fault Mode
(ref. ‘ TDF_’command)
Transmit Clock Activity Action
(ref. 'TCAA_' command).
DVB Framing Type
(ref. 'TDVB_' command).
Reserved
Interface Specific
Description
p1 = nnnnn-mmm.mmmmmm, code
rate/date rate in Mbps
p2 = nnn.nnnn, IF frequency in MHz
p3 = n, where n is 0 or 1 (0 = Off, 1 = On).
p4 = snn.n, transmitter output power level in
dBm.
p5 = snn.n, transmitter power offset level in
dBm.
p6 = n, where n is 0, 1, 2, 3
(0 = Off, 1 = Dual, 2 = Offset, 3 = Center)
p7 = n, where n is 0 or 1
(0 = NRM, 1 =INV)
p8 = n, where 'n' is '0' or ‘1’
(0 = Off, 1 = Last)
p9 = n, where 'n' is '0' or ‘1’
(0 = DVB-1, 1 = DVB-2)
p10 = n, where 'n' is ’0’ or ‘1’
(0 = Off , 1 = On)
p11 = n, where 'n' = ‘0’ or ‘1’
(0 = NRM, 1 = INV)
p12 = n, where 'n' = ‘0’ or ‘1’
(0 = NRM, 1 = INV)
p13 = n, where ‘n’ is ‘0’ or ‘1’
(0 = Off, 1 = On)
p14 = n, where ‘n’ is ‘0’, ‘1’, ‘2’
(0 = EXT, 1 = Data, 2 = Auto)
p15 = n, where ‘n’ is ‘0’, ‘1’, ‘2’
(0 = None, 1 = Data Stable, 2 = AIS)
p16 = n, where 'n' is '0' or ‘1’
(0 = Fault, 1 = Alarm)
p17 = n, where n = '1' , ‘2’, ‘3’
(1 = 188, 2 = None, 3 = 204)
