SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-11
5.6.1.5 CONFIGURATION:MODULATOR:TX-IF POWER LEVEL
TX POWER LEVEL
-10.0 dBm
Use this menu to program the modulator output power level.
Range available: +5 to -20 dBm, in 0.1 dBm steps.
On entry, the current transmitter power level is displayed with the flashing cursor on the
first character.
1 Press [ ↑] or [↓] to increase or decrease the output power level in 0.1 dB steps.
2 Press to execute the change.
5.6.1.6 CONFIGURATION:MODULATOR:ENERGY DISPERSAL
ENERGY DISPERSAL
(SCRAMBLER) ON
Use this menu to program the energy dispersal ON or OFF.
On entry, the current status of the DVB Energy Dispersal is displayed.
1 Press [ ↑] or [↓] to select ON or OFF.
2 Press to execute the change.
