SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-31
TX INTF FIRMWARE
FW/6220A
Press to show the FW Release date.
TX INTF FIRMWARE
11/25/97
Press to exit the data menu.
ASI LINK SELECT
B-LINK (J3)
This display shows the A-LINK (J4) or B-LINK (J3). Upon entry, the current status of the
mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
ASI LOOP BW
WIDE
Note: This is for ASI mode only.
This display shows the ASI Loop BW selection of either Wide or Narrow. Upon entry,
the current status of the mode type is displayed.
1 Press [ ↑] or [↓] to select an item.
2 Press to execute the change.
