SDM-2020 Satellite Modulator
Revision 7
Remote Control Operation MN/SDM2020M.IOM
A-31
Parameter
Type
Command/
Status/
Response
Description of Arguments
Comments
MCP
Command
Config.
Command:
Response:
ISEL_xxxxxx'cr'
ICLK_xxx'cr'
TDVB_xxxx'cr'
MF_nnn.nnnn'cr'
MR_nnnn_mmm.mmmmmm'cr'
MPO_snn.n'cr'
MOP_snn.n'cr'
SE_xxx'cr'
TCP_xxx'cr'
TDP_xxxx'cr'
TDF_xxxx'cr'
ISP_xxx'cr'
SYNC_xxxx'cr'
MSR_xxx'cr'
MT_xxxx'cr'
TXPU_xxxxx'cr'
COM_xxxxxx'cr'
ASI_x'cr'
RTSM_xxxx'cr'
RTSS_xxxx'cr'
CTSS_xxxx'cr'
DMS_xxxx'cr'
ST_xxxx'cr'
TCAA_xxxxx'cr'
RF_xxx'cr'
ASLB_xxxxxx’cr’’lf’]
Interface Select
Interface Mode
DVB Framing Type
Modulator Frequency
Modulator Rate
Modulator Power Offset
Modulator Output Power
Scrambler Enable (ON/OFF)
Transmit Clock Phase
Transmit Data Phase
Transmit Data Fault
Transmit 2047 Pattern Generator
Transmit Sync Select
Modulator Spectrum Rotation
Modulator Type
Transmit IF Output Power-up Configuration
Carrier Only Mode
ASI Input
RTS Mode Control
RTS State Control
CTS State Control
DM State Control
ST State Control
TX Clock Activity Action
RF Output (ON/OFF)
ASI Loop BW (Wide/Narrow)
ICS
Command
Config.
Command:
Response:
TCP_xxx'cr'
TDP_xxxx'cr'
ISP_xxx'cr'
SYNC_xxxx'cr'
TDF_xxxx'cr'
TDVB_xxxx'cr'
INID_xxxxxxxxx'cr'
ISEL_xxxxxx'cr'
ICLK_xxx'cr'
ASI_x'cr'
RTSM_xxx'cr'
RTSS_xxx'cr'
CTSS_xxx'cr'
DMS_xxx'cr'
ST_xxx'cr'
TCAA_xxxxx'cr’
ASLB_xxxxxx’cr’’lf’]
Transmit Clock Phase
Transmit Data Phase
Transmit 2047 Pattern Generator
Transmit Sync Select
Transmit Data Fault
DVB Framing Type
Interface Identification
Interface Select
Interface Mode
ASI Input
RTS Mode Control
RTS State Control
CTS State Control
DM State Control
ST State Control
TX Clock Activity Action
ASI Loop Bandwidth
