SDM-2020 Satellite Modulator Revision 7
Front Panel Operation MN/SDM2020M.IOM
5-7
5.6 O
PENING
S
CREEN
This screen is displayed whenever power is first applied to the unit:
SDM-2020 MOD
VER: 9.1.2
Press any key to go to the top level selection screen.
5.6.1 F
UNCTION
S
ELECT
:C
ONFIGURATION
FUNCTION SELECT
CONFIGURATION
The following choices are present:
Modulator This menu branch permits the user to fully configure the modulator.
Interface This branch permits the user to fully configure the transmit phase of the
modulator.
Save The user can save up to 10 different modulator configurations in the non-
volatile memory of the unit.
Recall The user can recall the 10 different modulator configurations from the non-
volatile memory of the unit.
5.6.1.1 F
UNCTION
S
ELECT
:C
ONFIGURATION
:MODULATOR
CONFIGURATION
MODULATOR
Use this menu to configure the unit in a step-by-step process using each successive menu.
Use the [ ↑ ] [↓ ] arrows to make the desired selection, then press .
