Comtech EF Data SDM-2020 User Manual
Page 149
SDM-2020 Satellite Modulator
Revision 7
Data Interfaces
MN/SDM2020M.IOM
12-2
SMPTE 310
Recovery
J6
Signal
Processing
Au
xili
ar
y
MF
DF
/CD
J4
J3
SMPTE 310
Generator
Loopback
Level
Translators
M&C
Modulator /
Demodulator
Interface
Terrestrial
Interface
Tx
Data
75 Ohm
BNC-F
Rx
Data
75 Ohm
BNC-F
DC
Power
J5
RTS
96 Pin
DIN
Figure 12-1. SMPTE-310M Interface Block Diagram
