SDM-2020 Satellite Modulator
Revision 7
Remote Control Operation MN/SDM2020M.IOM
Parameter
Command/
Status/
Type
Response
Description of Arguments
Comments
Boot Firmware
Information
Command:
Response:
Ver:_xxx_yyy.zzz'cr'
FW/nnnnnn-ddrr’cr'
mm/dd/yyyy'cr''lf']
Where:
xxx.yyy.zzz = Software version number
(0.0.0 to 999.999.999).
nnnnnn = Firmware number (0 to 999999).
dd = Firmware dash number (0 to 99).
rr = Firmware revision (-, or A to ZZ).
Encoder Firmware
Information (EFI)
Command:
Response:
FW/nnnnn-ddrr'cr'
Mm/dd/yyyy'cr''lf']
Where:
nnnnn = Firmware number (0 to 65535).
dd = Firmware dash number (0 to 99).
rr = Firmware revision (-, or A to ZZ).
Reed-Solomon
Firmware
Information
(RSFI)
Command:
Response:
FW/nnnnn-ddrr'cr'
Mm/dd/yyyy'cr''lf']
Where:
nnnnn = Firmware number (0 to 65535).
dd = Firmware dash number (0 to 99).
rr = Firmware revision (-, or A to ZZ).
Interface Firmware
Information
(As Required)
Command:
Response:
FW/nnnnn-ddrr'cr'
mm/dd/yyyy'cr''lf']
Where:
nnnnn = Firmware number (0 to 65535).
dd= Firmware dash number (0 to 99).
rr = Firmware revision (-, or A to ZZ).
Modem Options/
Misc. Information
Command:
Response:
s,OEM_LCD'cr'
s,16QAM'cr'
s,8PSK'cr''lf']
Where:
s = 0 (Not Installed, Not Upgradable)
- = (Not Installed, FAST Upgradable)
+ = (Installed)
(- or +) OEM LCD option
(- or +) 16QAM Code Rate option
(- or +) 8PSK Code Rate option
State of Product
Command:
Response:
Product address: abc’cr’
Baud format: abc’cr’
Baud rate: rrrrr bps’cr’
Comm type:
Where: a = Number of data bits (7)
b = Parity type (O,E,N)
c = Number of stop bits (1)
rrrrr = baud rate (150, 300, 600,
1200, 2400, 4800, 9600, 14.4K,
19.2K)
strings explaining communication
hardware
type:
RS-485,
2
wire
RS-485,
4
wire
RS-232
strings explaining the intention of
the
product:
“Under normal system operation”
“REFLASH of BULK firmware
required”
“REFLASH of M&C firmware
required”
A-25
