SDM-2020 Satellite Modulator
Revision 7
ASI/LVDS Data Interfaces MN/SDM2020M.IOM
13-10
13.1.8
ASI/LVDS I
NTERFACE
D
EFAULTS
Interface Select
ASI
TX-IF Control
Off
Data or Clock
Normal
Frame Format
188
Loss of Data
Alarm
Clock/Data Sync
Correlate on data
Loopback / Loop Thru OFF
Loop Bandwidth
Wide
ASI Link Select
J3
