BIOS
ATCA-7365 Installation and Use (6806800K65M) 94
When you are not sure about configuration settings, restore the default values. This option is
provided in case a value has been changed and you wish to reset settings. To restore the default
values, press in Setup.
4.2 Accessing the Blade Using the Serial Console
Redirection
The blade’s firmware provides a serial console redirection feature allowing remote access to
the blade through a terminal connected to the blade's serial interface.
The terminal can be connected to display VGA text information. Terminal keyboard input is
redirected and treated as a normal PC keyboard input. The serial console redirection feature
can be configured via a setup utility.
4.2.1 Requirements for Serial Console Redirection
For serial console redirection, the following is required:
 Terminal or terminal emulation which supports a VT100 mode
 NULL-modem cable
Terminal emulation programs such as TeraTermPro can be used. In order to use TeraTermPro
using the function keys, the keyboard configuration file of TeraTermPro has to be modified as
follows:
 Loading the BIOS default values will affect all setup items and will reset options
previously altered.
 If you set the default values, the displayed default values takes effect only after the BIOS
setup is saved and closed.
Table 4-1 BIOS Key Codes for Terminal Emulation Program
Function Key Key Code
PF1 59
PF2 60
