Controls, Indicators, and Connectors
ATCA-7365 Installation and Use (6806800K65M) 75
The meaning of these LEDs is described in the following table.
Table 3-1 Face Plate LEDs
LED Description
OOS Out Of Service
This LED is multicolored (red/amber) and is programmable through IPMC.
Its default color is red and its local control state (on or off) reflects the payload
power state (on or off).
It permits override control by higher layer software, such as middle ware or
applications, as specified in PICMG 3.0 specification.
IS Payload Power Status
This LED is multicolored (green/red/amber) and is programmable through
IPMC.
Its default color is green and its local control state is off.
It permits override control by higher layer software, such as middle ware or
applications, as specified in PICMG 3.0 specification.
ATN Attention
This LED has amber color and is programmable through IPMC.
Its local control state is off.
It permits override control by higher layer software, such as middle ware or
applications, as specified in PICMG 3.0 specification.
ETH Status LEDs The Ethernet connector provides two status LEDs
Link (upper)
Green: Link is available
Off: No link
Activity (lower)
Yellow: Activity
Off: No activity
U1, U2 Base interface activity is visualized via FPGA LEDs U1 and U2
U3 User LED, selectable color via FPGA register.
Colors: red, green, orange
