Maps and Registers
ATCA-7365 Installation and Use (6806800K65M) 195
6.4.7 Serial Line Routing Register
6.4.8 IPMC Power Level Register
Table 6-45 Serial Line Routing Register
Address Offset: 0x05
Bit Description Default Access
1:0 Inverted level of signals SEL_SERIAL[1:0], which are
controlled by switches SW2.2 and SW2.1. Switch
setting may be overwritten by IPMC Software:
00: COM1 to Face Plate and COM2 to RTM
01: COM1 to RTM and COM2 to Face Plate
10: Reserved
11: Reserved Ext.
(SW2.2
1 , SW2.1)
00: (OFF,OFF)
01: (OFF,ON)
10: (ON,OFF)
11: (ON,ON)
1. The Signal SEL_SERIAL[1] is reserved. The switch SW2.2 should always be “OFF” and IPMC should not overwrite
the default value.
r
7:2 Reserved 0 r
Table 6-46 IPMC Power Level Register
Address Offset: 0x06
Bit Description Default Access
7:0 IPMC Power Level. IPMC writes a value, which
correspond to a defined power level. PWR_GOOD:0 IPMC: r/w
LPC: r
