BIOS
ATCA-7365 Installation and Use (6806800K65M) 111
4.5.2.7 Advanced -> Super IO Configuration
4.5.2.7.1 Advanced -> Super IO Configuration -> Serial Port 0 Configuration
Device Reset timeout 10..40 seconds
Default 20 sec. USB mass storage device Start Unit command
timeout: 10, 20, 30, 40 seconds.
Controller Timeout 1..20 seconds
Default 20 sec. The time out value for Control, bulk & interrupt
transfer: 1, 5, 10 , 20 seconds.
USB Device Name Auto, Floppy, Forced FDD,
Hard Disk, CD-ROM Mass storage device emulation type.
"Auto" enumerates devices according to its media
format. Devices less than 530 MB are detected as
floppy. Optical drives are emulated as CD-ROM.
drives with no media will be emulated according to a
drive type.
Forced FDD option can be used to force HDD
formatted drive to boot as FDD (e.g. ZIP drive).
Table 4-13 Advanced -> USB Configuration (continued)
Item Values Description
Table 4-14 Super IO Configuration -> Serial Port 0 Configuration
Item Values Description
Serial Port Enabled (Default)
Disabled Enable or disable Serial Port (COM 0).
Change Settings Auto,
IO=3F8h IRQ=4 (Default),
IO=3F8h IRQ=3,4,5,6,7,10,11,12,
IO=2F8h IRQ=3,4,5,6,7,10,11,12,
IO=3E8h IRQ=3,4,5,6,7,10,11,12,
IO=2E8h IRQ=3,4,5,6,7,10,11,12
Select IO port and Interrupt settings for COM 0
