Zone 3 contains the two connectors P30 and P32. They are used to connect an RTM to the
blade and carry the following signals:
 Serial (RS232_x_yyyy)
 Serial ATA (SATAx_yyy)
 USB (USBxy)
 PCI Express (PCIEx_yyy)
 IPMI (IPMB1_xxx, ISMB_xxx)
 Power (VP12_RTM, V3P3_RTM, VP5_RTM)
Figure 3-21 P23 Backplane Connector Pinout - Rows E to H
