6.3.3
Super IO Configuration Register
After a LPC Reset (ICH_PLTRST_ is asserted) or “Power On Reset” the Super IO is in the Run
Mode with the UARTs disabled. They may be configured using the LPC IO Address Range SIW
(INDEX and DATA) by placing the Super IO into Configuration Mode. The BIOS uses these
configuration addresses to initialize the logical devices at POST. The INDEX and DATA
addresses are only valid when the Super IO is in Configuration State. The INDEX and DATA
addresses are effective only when the Super IO is in the Configuration State. When the Super
IO is not in the Configuration State, reads return 0xFF and write data is ignored.
6.3.3.1
Entering the Configuration State
The device enters the Configuration State by the following contiguous sequence:
1. Write 68 to Configuration Index Port.
2. Write 08 to Configuration Index Port.
6.3.3.2
Configuration Mode
The system sets the logical device information and activates desired logical devices trough the
INDEX and DATA ports.
Table 6-9 Super IO Configuration Index Register
LPC I/O Address: 0x4E
Bit
Description
Default
Access
7:0
INDEX. Configuration
Index.
0xff
LPC: r/w
Table 6-10 Super IO Configuration Data Register
LPC I/O Address: 0x4F
Bit
Description
Default
Access
7:0
DATA Configuration Data. 0xff
LPC: r/w
