BIOS
ATCA-7365 Installation and Use (6806800K65M) 136
PCI Information Definition:
4.12.4.5 PCI System Error
This event is generated from the runtime error logging module. See Runtime Error Logging on
page 125 .
Table 4-39 PCI Information Definition
Bit Description
0-7 reserved
8-15 PCI Function
16-23 PCI Device
24-31 PCI Bus number
Table 4-40 Multi-bit ECC Memory Error Event Format
Offset Name Format Description
00h Event Type BYTE Event Type = 0Ah
01h Length BYTE always 0Ch
02h-07h Date/Time Fields BYTE These fields contain the BCD
representation of the date and time
08h-0Bh PCI Information UINT32 OEM extension
Table 4-41 Memory InformaTion Definition
Bit Description
0-7 reserved
8-15 PCI Function
16-23 PCI Device
24-31 PCI Bus number
