32

Installation

2.14 CN4 pin assignments: Simultaneous Start/Stop
(PCI-8164 only)

CN4 is for simultaneous start/stop signals for multiple axes or mul-
tiple cards.

Note: +5V and GND pins are provided by the PCI Bus power.

No. Name

Function (Axis)

1

DGND

Bus power ground

2

STP

Simultaneous stop signal input/output

3

STA

Simultaneous start signal input/output

4

STP

Simultaneous stop signal input/output

5

STA

Simultaneous start signal input/output

6

VCC

Bus power output, +5V
