Sj1-sj4 cn1 – ADLINK PCI-8164 User Manual
Page 291

Connection Example
279
SJ1-SJ4
CN1
No.
Name
I/O
Function
No
Name
I/O
Function
1
OUT+
O
Pulse Signal (+)
6
ALM
I
Servo Alarm
2
OUT-
O
Pulse Signal (-)
7
+5V
O
Voltage output
3
DIR+
O
Direction Signal (+)
8
Servo ON
O
Servo On
4
DIR-
O
Direction Signal (-)
9
+5V
O
Voltage output
5
EZ+
I
Index Signal
10
IGND
--
Isolated Ground
No.
Name
I/O
Function
1
EX+24V
I
External Power Supply Input (+24V DC ± 5%)
2
EXGND
--
External Power Supply Ground
