40 SD/PCS1 I Ramp-down signal 90 SD/PCS3 I Ramp-down signal
41 ORG1 I Origin signal, 91 ORG3 I Origin signal,
42 EGND Ext. power ground 92 EGND Ext. power ground
43 PEL2 I End limit signal (+), 93 PEL4 I End limit signal (+),
44 MEL2 I End limit signal (-), 94 MEL4 I End limit signal (-),
45 CMP2 O Position compare output 95 LTC4 I Position latch input,
46 SD/PCS2 I Ramp-down signal 96 SD/PCS4 I Ramp-down signal
47 ORG2 I Origin signal, 97 ORG4 I Origin signal,
48 EGND Ext. power ground 98 GND Ext. power ground
49 EGND Ext. power ground 99 E_24V Ext. power supply, +24V
50 EGND Ext. power ground 100 E_24V Ext. power supply, +24V
