Installation 27
2.10 J4 pin assignments: Manual Pulse Input
(PXI-8164 only)
No. Name Function No. Name Function
1 DGND Bus power ground 2 PB4 Axis 3 Pulser PHB
3 PA4 Axis 4 Pulser PHA 4 PB3 Axis 2 Pulser PHB
5 PA3 Axis 3 Pulser PHA 6 VCC Bus Power +5V
7 DGND Bus power ground 8 PB2 Axis 1 Pulser PHB
9 PA2 Axis 1 Pulser PHA 10 PB1 Axis 0 Pulser PHB
11 PA1 Axis 0 Pulser PHA 12 VCC Bus Power +5V
13 -- N/A 14 -- N/A
15 -- N/A 16 -- N/A
17 -- N/A 18 -- N/A
19 -- N/A 20 -- N/A
