180 Function Library
Visual Basic (Windows 95/NT/2K/XP)
B_8164_set_pls_outmode (ByVal AxisNo As Integer,
ByVal pls_outmode As Integer) As Integer
B_8164_set_pls_iptmode (ByVal AxisNo As Integer,
ByVal pls_iptmode As Integer, ByVal
pls_logic As Integer) As Integer
B_8164_set_feedback_src (ByVal AxisNo As Integer,
ByVal Src As Integer) As Integer
@ Argument
AxisNo: The designated axis number to configure pulse Input/
Output.
pls_outmode: Setting of command pulse output mode
pls_iptmode: setting of encoder feedback pulse input mode
pls_logic: Logic of encoder feedback pulse
X pls_logic=0, Not inverse direction
X pls_logic=1, Inverse direction
Value Meaning Notes
0 OUT/DIR OUT Falling edge, DIR+ is high level
1 OUT/DIR OUT Rising edge, DIR+ is high level
2 OUT/DIR OUT Falling edge, DIR+ is low level
3 OUT/DIR OUT Rising edge, DIR+ is low level
4 CW/CCW Falling edge
5 CW/CCW Rising edge
6 4XA/B Falling edge
7 4XA/B Rising edge
Value Meaning
0 1X A/B
1 2X A/B
2 4X A/B
3 CW/CCW
