Installation 29
2.12 J3 pin assignments: Isolated DIO
(PXI-8164 only)
No. Name Function No. Name Function
1 DICOM Digital In Common 2 DOCOM Digital Out Common
3 DI0 Input Channel 0 4 DO0 Output Channel 0
5 DI1 Input Channel 1 6 DO1 Output Channel 1
7 DICOM Digital In Common 8 DOCOM Digital Out Common
9 DI2 Input Channel 2 10 DO2 Output Channel 2
11 DI3 Input Channel 3 12 DO3 Ouput Channel 3
13 DICOM Digital In Common 14 DOCOM Digital Out Common
15
-- N/A 16 -- N/A
17 -- N/A 18 -- N/A
19 -- N/A 20 -- N/A
