EVCO S.p.A. c-pro 3 NODE kilo AHU | Application manual ver. 1.0
page 56 of 114
6.9 Table of types of configurable machines
Once the parameters are set wizard, you have configured one of 153 possible machines.
The following table shows the machines with configurable drive type to DOUBLE FLOW:
Machine DOUBLE FLOW
Code Unit Type Fans Type Coil 1 type Coil 2 type
1 Double flow ON-OFF Water (C) NO
2
Double flow
ON-OFF Water (C) Water (H)
3
Double flow
ON-OFF Water (C) Electrical 1st
4
Double flow
ON-OFF Water (C) Electrical 2st
5
Double flow
ON-OFF Water (C) Electrical mod
6
Double flow
ON-OFF Water (H/C) NO
7
Double flow
ON-OFF
Water (H/C)
Water (H)
8
Double flow
ON-OFF Water (H/C) Electrical 1st
9
Double flow
ON-OFF
Water (H/C)
Electrical 2st
10
Double flow
ON-OFF Water (H/C) Electrical mod
11
Double flow
ON-OFF Water (H) NO
12
Double flow
ON-OFF Water (H) Electrical 1st
13
Double flow
ON-OFF Water (H) Electrical 2st
14
Double flow
ON-OFF Water (H) Electrical mod
15
Double flow
ON-OFF Electrical 1st NO
16
Double flow
ON-OFF Electrical 2st NO
17
Double flow
ON-OFF Electrical mod NO
18
Double flow
3 Speed Water (H) NO
19
Double flow
3 Speed Water (H) Water (H)
20
Double flow
3 Speed Water (H) Electrical 1st
21
Double flow
3 Speed
Water (H)
Electrical 2st
22
Double flow
3 Speed Water (C) Electrical mod
23
Double flow
3 Speed
Water (H/C)
NO
24
Double flow
3 Speed Water (H/C) Water (H)
25
Double flow
3 Speed Water (H/C) Electrical 1st
26
Double flow
3 Speed Water (H/C) Electrical 2st
27
Double flow
3 Speed Water (H/C) Electrical mod
28
Double flow
3 Speed Water (H) NO
29
Double flow
3 Speed Water (H) Electrical 1st
30
Double flow
3 Speed
Water (H)
Electrical 2st
31
Double flow
3 Speed Water (H) Electrical mod
32
Double flow
3 Speed Electrical 1st NO
33
Double flow
3 Speed Electrical 2st NO
34
Double flow
3 Speed Electrical mod NO
35
Double flow
Modulating
Water (C)
NO
36
Double flow Modulating Water (C) Water (H)
37
Double flow Modulating Water (C)
Electrical 1st
38
Double flow Modulating Water (C) Electrical 2st
39
Double flow Modulating Water (C) Electrical mod
40
Double flow Modulating Water (H/C) NO
41
Double flow Modulating Water (H/C) Water (H)
42 Double flow
Modulating
Water (H/C) Electrical 1st
