EVCO S.p.A. c-pro 3 NODE kilo AHU | Application manual ver. 1.0
page 102 of 114
0x0286 647 out_Humidifier 0.00 0.00 100.00 R/W
0x0287 648 out_MixDamper 0.00 0.00 100.00 R/W
0x0288 649 out_Recover 0.00 0.00 100.00 R/W
0x0300 769 PackedAlarm_1 0 0 65535 R/W
0x0301 770 PackedAlarm_2 0 0 65535 R/W
0x0400 1025 Status_OnOff_bySUP 0 0 1 R/W
0x0401 1026 Status_MOde_bySUP 0 0 1 R/W
0x0402 1027 Status_En_OffsetSP_bySUP 0 0 1 R/W
0x0500 1281 CLOCK_RTC ( Low ) - 01/01/2000 19/01/2068 03:14:07 R/W
0x0501 1282 CLOCK_RTC ( High )
0x0502 1283 statusUnit 0 0 255 R/W
0x0503 1284 v_MOdE 1 0 1 R/W
0x0504 1285 Active_SetPoint_Environment 0.0 -15.0 158.0 R/W
0x0505 1286 actual_SupplySetPoint 0.0 -15.0 158.0 R/W
0x0506 1287 actual_SupplySetPoint_Heating 0.0 -15.0 158.0 R/W
0x0507 1288 actual_SupplySetPoint_Cooling 0.0 -15.0 158.0 R/W
0x0508 1289 actualSPhum 0 -32768 32767 R/W
0x0509 1290 actualSPdeHhum 0 -32768 32767 R/W
0x050A 1291 Status_SupplyFan 0 0 6 R/W
0x050B 1292 Status_ReturnFan 0 0 6 R/W
0x050C 1293 Status_Pump1 0 0 4 R/W
0x050D 1294 Status_Pump2 0 0 4 R/W
0x050E 1295 Status_Humidifier 0 0 4 R/W
0x050F 1296 Status_Recover 0 0 4 R/W
0x0510 1297 statusHeater1 0 0 5 R/W
0x0511 1298 statusHeater2 0 0 5 R/W
0x0512 1299 Status_extDamper 0 0 5 R/W
0x0513 1300 Status_MixAirShutter 0 0 5 R/W
0x0514 1301 Position_MixShutter 0.00 0.00 100.00 R/W
0x0515 1302 UI_TBactual 0 0 255 R/W
0x0516 1303 TBoffset 0.0 -3276.8 3276.7 R/W
0x0517 1304 limitC 0.00 0.00 100.00 R/W
0x0518 1305 limitH 0.00 0.00 100.00 R/W
0x0519 1306 Request_AirQuality 0.00 0.00 100.00 R/W
0x051A 1307 Req_FreeCoolingHeating 0.00 0.00 100.00 R/W
0x051B 1308 DeHumid_ValveRequest 0.00 0.00 100.00 R/W
0x0600 1537 F1_Monday_p1 0 0 4 R/W
0x0601 1538 F1_Monday_h1 ( Low ) 00:00:00 00:00:00 23:59:59 R/W
0x0602 1539 F1_Monday_h1 ( High )
0x0603 1540 F2_Monday_p2 0 0 4 R/W
