EVCO S.p.A. c-pro 3 NODE kilo AHU | Application manual ver. 1.0
page 28 of 114
PC05
Enable cycles for air quality sensors for
ambient temperature (when probe is
restarting)
NO (0) NO (0) YES (1) - IS-R
PC06
Wait time prior to fan activation for air
quality sensors
6 1 99 Min IS-R
PC07
Fan activation time for air quality
sensors
2 1 30 Min IS-R
PC08
Activate both fans for air quality
sensors
0 : NO – Only activate pickup fan
1 : YES – Activate both fans
NO (0) NO (0) YES (1) - IS-R
PC61 Summer commutation set point 20.0 PC62 70.0 °C IS-R
PC62 Winter commutation set point 10.0 0.0 PC61 °C IS-R
PC63
Active probe for automatic changeover
0: Outdoor temp.
1: flow temp.
2: environment/return temp.
0 0 1 IS-R
FANS
PF01
Types of controls for fans:
0: On/Off steps regulation
1: Modulating steps regulation
2: Modulating ramp regulation
3: Static pressure ramp regulation
4: AQ steps regulation
5: Modulating AQ regulation
6: Regulation on time bands
7: Manual regulation
7 0 7 - IS-F
PF02 Differentials for fan control 5.0 0.0 30.0 °C IS-F
PF01=0
PF01=1
PF03
Minimum speed for the control of fan
modules
40.0 0.0 PF04 % IS-F
PF04
Maximum speed for the control of fan
modules
100.0 PF03 100.0 % IS-F
PF05
Minimum time between the start-up of
flow and return fans.
20 0 999 Sec IS-F
PF08
Differential of On/Off steps on ramp of
control of fan modules
0.0 0.0 60.0 % IS-F PF01=2
PF09
Delay time (on and off) of On/Off steps
on ramp of control of fan modules
10 0 999 Sec IS-F PF01=2
PF10
Flow and return fan speed in room
sensor alarm
30.0 0.0 100.0 % IS-F
PF11 Static pressure control set point ramp 1.0 0.0 10.0 bar/min IS-F PF01=3
PF12 Static pressure control set point 3.0 0.0 10.0 Bar IS-F PF01=3
PF13
Static pressure control proportional
band
0.5 0.0 5.0 Bar IS-F PF01=3
PF14 Static pressure control integral time 0 0 300 Sec IS-F PF01=3
PF15 Enable fan limitation 0 (No) 0 (No) 1 (Yes) - IS-F
PF16 Min. temperature of limitation 10.0 -15.0 70.0 °C IS-F
