EVCO S.p.A. c-pro 3 NODE kilo AHU | Application manual ver. 1.0
page 41 of 114
HB12
Assignment DI12
(see table par. 4.1.2)
0 0 18 - IS-DI
HB13
Assignment DI13
(see table par. 4.1.2)
0 0 18 - IS-DI
HARDWARE AO PARAMETERS
HC01
Assignment AO1
(see table par. 4.1.4)
0 0 8 - IS-AO
HC02
Assignment AO2
(see table par. 4.1.4)
0 0 8 - IS-AO
HC03
Assignment AO3
(see table par. 4.1.4)
0 0 8 - IS-AO
HC04
Assignment AO4
(see table par. 4.1.4)
0 0 8 - IS-AO
HC05
Assignment AO5
(see table par. 4.1.4)
0 0 8 - IS-AO
HC06
Assignment AO6
(see table par. 4.1.4)
0 0 8 - IS-AO
HCF1 Flow fan PWM frequency 10 10 2000 Hz IS-AO
HCF2 Return fan PWM frequency 10 10 2000 Hz IS-AO
HARDWARE DO PARAMETERS
HD01
Assignment DO1
(see table par. 4.1.3)
0 0 18 - IS-DO
HD02
Assignment DO2
(see table par. 4.1.3)
0 0 18 - IS-DO
HD03
Assignment DO3
(see table par. 4.1.3)
0 0 18 - IS-DO
HD04
Assignment DO4
(see table par. 4.1.3)
0 0 18 - IS-DO
HD05
Assignment DO5
(see table par. 4.1.3)
0 0 18 - IS-DO
HD06
Assignment DO6
(see table par. 4.1.3)
0 0 18 - IS-DO
HD07
Assignment DO7
(see table par. 4.1.3)
0 0 18 - IS-DO
HD08
Assignment DO8
(see table par. 4.1.3)
0 0 18 - IS-DO
HD09
Assignment DO9
(see table par. 4.1.3)
0 0 18 - IS-DO
HD10
Assignment D10
(see table par. 4.1.3)
0 0 18 - IS-DO
HD11
Assignment D11
(see table par. 4.1.3)
0 0 18 - IS-DO
Note: Once the machine parameters have been configured, and every time the configuration parameters are modified,
it is advisable to shut down the machine and restart the plant, to enable the card to reconfigure itself correctly.
