EVCO S.p.A. c-pro 3 NODE kilo AHU | Application manual ver. 1.0
page 36 of 114
PH44
Type of expelled air temperature sensor
0: PTC
1: NTC
2: PT1000
3: NTC 10K-2
4: NTC 10K-3
1 0 4 - IS-V
PH45
Type of channel pressure sensor
0: 0-20mA
1: 4-20mA
2: 0-5V
3: 0-10V
3 0 3 - IS-V
PH46
Type of air quality sensor
0: 0-20mA
1: 4-20mA
2: 0-5V
3: 0-10V
3 0 3 - IS-V
PH47
Type of flow humidity sensor
0: 0-20mA
1: 4-20mA
2: 0-5V
3: 0-10V
3 0 3 - IS-V
PH48
Type of remote set point potentiometer
sensor
0: 0-20mA
1: 4-20mA
2: 0-5V
3: 0-10V
3 0 3 - IS-V
PH49
Type of damper potentiometer sensor
0: 0-20mA
1: 4-20mA
2: 0-5V
3: 0-10V
3 0 3 - IS-V
PH50:
Logic for Digital inputs for remote
On/Off:
NO (0) NO (0) NC (1) - IS-V
PH51
Logic for Digital inputs used for fans
alarm
NO (0) NO (0) NC (1) - IS-V
PH52
Logic for Digital inputs used for the
alarm air flow
NO (0) NO (0) NC (1) - IS-V
PH53
Logic for Digital inputs used for alarm
fire-smoke
NC (1) NO (0) NC (1) - IS-V
PH54
Logic for Digital inputs used for coil 1
pump alarm
NO (0) NO (0) NC (1) - IS-V
