EVCO S.p.A.
c-pro 3
NODE kilo AHU | Application manual ver. 1.0
page 38 of 114
PH80
Type of coil 1 AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH81
Type of coil 2 AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH82
Type of flow fan AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH83
Type of return fan AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH84
Type of mixing chamber damper AO
sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH85
Type of humidifier AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH86
Type of heating element AO sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH87
Type of rotary recovery device AO
sensor
1=0-20mA
2=4-20mA
3=0-10V
3
1
3
-
IS-V
PH90
Minimum value for the set point
modification potentiometer
-5.0
-10.0
PH91
°C
IS-V
PH91
Maximum value for the set point
modification potentiometer
5.0
PH90
10.0
°C
IS-V
PH92
Meaning of the icon summer/winter
0: Sun/Summer - Snow/Winter
1: Sun/Winter
- Snow/Summer
0
0
1
IS-V
DEFAULT
PH15
Restoring the manufacturers’ default
parameters
NO (0)
NO (0)
YES (1)
-
IS-D
Wait
for
the value
NO(0)
upon
completion
of restore
