5-54 IntelliServe



User’s Guide

CONFIDENTIAL – Covered by ADS Terms of Use and Confidentiality Agreement in Contract

Note: Some of the selected monitoring points/locations may not have
data in database for the specified time period. In addition, every time
you change the date range, you must refresh the list of entities by
clicking on the Get Entities button.

7. Select the checkboxes on the Available Data Entities table corresponding

to the cumulative rain and/or rain intensity entities you want to graph.

8. Select the period over which you want IntelliServe to display the data on

the screen at one time from the Display Format drop-down list.

9. (optional) Select the Tabular Data checkbox to include an option on the

hydrograph(s) for viewing the data in tabular format.

10. Click on one of the following buttons based on the type of graphing method

you want to apply to the selected data.

 Graph Select this button to display the designated data for all selected

monitoring points on a single hydrograph.

 Flip Chart Select this button to display the designated data for each

selected monitoring point on a separate hydrograph.

An IntelliServe Hydrograph dialog displays the selected data in the chosen
format. Use the scroll bar at the bottom of the hydrograph to scroll through the
data if more data has been selected than can display on the screen at one time.
For multiple hydrographs, page through use the hydrographs representing the
individual monitoring points/locations arrow using the arrow buttons or by
clicking on the number links directly above the hydrograph.
