4.3 Configuration
Liquino 711, Instructions for use 70
>dosi ng uni t s Configuration of dosing units
If dosing units with different lengths and diameters of tubing are used which do not correspond to the standard dimensions then
special types of dosing units can be defined (max. 10). If such a dosing unit is used then its name must be entered under 'Configu-
ration>Manual operation' or in the method with which it is to be used.
dos. uni t : D1 selection list, see 'I D' below selects dosing unit.
I D D1 12 ASCII characters as wished name of type of dosing unit
l engt h t ube1 400 mm 0…9999 mm length of tubing at Dosino Port 1 (dosing port)
di am. t ube1 2. 0 mm 0.1…9.0 mm diameter of tubing at Port 1
l engt h t ube2 250 mm 0…9999 mm length of tubing at Dosino Port 2 (filling port, dipping
tubing in the bottle)
di am. t ube2 2. 0 mm 0.1…9.0 mm diameter of tubing at Port 2
l engt h t ube3 0 mm 0…9999 mm length of tubing at Dosino Port 3 (free port)
l engt h t ube4 0 mm 0…9999 mm length of tubing at Dosino Port 4 (waste port in bottle)
>RS232 set t i ngs Serial RS232 interface settings
It is absolutely essential that the settings at the RS232 interface are in agreement with the corresponding data transmission pa-
rameters of the instrument connected.
baud r at e: 9600 300; 600; 1200; 2400; 4800;
9600; 19200; 38400; 57600
data transmission rate
dat a bi t s: 8 7; 8 number of data bits
st op bi t s:
1
1; 2 number of stop bits
par i t y: none even; odd; none type of parity check
handshake: Har dwar e Hardware; SWChar; SWline;
none
type of handshake
RS cont r ol : on on; off blocks data reception
>r epor t header Definition of the user-defined report header
H1 21 ASCII characters as wished contents of first header line
H2 21 ASCII characters as wished contents of second header line
H3 21 ASCII characters as wished contents of third header line
>GLP er r or l i mi t s Configuration of the error limits in the GLP test mode
>>er r . l i mi t s 2mL- cyl . Submenu for 2 mL dosing units
er r or max. vol . +/ - 6 µL 1…999 µL maximum volume error
sl ope +/ - 0. 003 0.001…0.1 maximum variation in slope
i nt er cept +/ - 6 µL 1…99 µL maximum y-axis intercept
>>er r . l i mi t s 5mL- cyl . Submenu for 5 mL dosing units
er r or max. vol . +/ - 15 µL 1…999 µL maximum volume error
sl ope +/ - 0. 003 0.001…0.1 maximum variation in slope
i nt er cept +/ - 15 µL 1…99 µL maximum y-axis intercept
>>er r . l i mi t s 10mL- cyl . Submenu for 10 mL dosing units
er r or max. vol . +/ - 30 µL 1…999 µL maximum volume error
sl ope +/ - 0. 003 0.001…0.1 maximum variation in slope
i nt er cept +/ - 20 µL 1…99 µL maximum y-axis intercept
