￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 5 Operation
862 Compact Titrosampler ￭￭￭￭￭￭￭￭ 67
3 Configure the measuring mode
￭ Select the desired electrode from the sensor list.
The selection depends on the measuring mode. Sensors are
defined under System
▶ Sensors.
￭ Enter the measuring temperature if no temperature sensor is con-
nected. If a temperature sensor is connected then the tempera-
ture will be measured automatically.
This temperature is used for automatic temperature compensation
with pH measurements.
4 Start the measurement
￭ Press [START].
The status changes to busy. The current measured value and the
measuring temperature are displayed.
5 Stop the measurement
￭ Press [STOP] or [BACK].
The measurement is stopped. The status changes back again to
ready. If you stop the measurement with [BACK], then the dialog
will also be exited.
5.11.5 Stirring
You can control a connected stirrer manually.
Proceed as follows:
1 Open the manual control
￭ In the main dialog, select Menu and press [OK].
The main menu opens.
￭ Select the menu item Manual control and press [OK].
Manual control opens.
