7
●
Data Streams
●
●
●
●
●
239
In order to convert a legacy Module Relative Display to an Element Relative
Display you must first migrate modules in the Module Database to elements in the
AF database. MDB to AF migration is handled upon upgrade to FactoryTalk
Historian SE 2.3. See the
FactoryTalk Historian MDB to AF Transition Guide
for
further details.
Connect to an AF Database
Use the Select Database dialog box to find and connect to AF databases.
1. Click File > PI systems. The Select Database dialog box appears.
2. Use the System list to connect to an AF System that contains an AF
database you wish to use. The
button launches the Systems dialog
box, where you can connect to other AF Systems.
