FactoryTalk Historian ProcessBook User Guide
84
3. Click the arrow on the right side of the Fill Color button to display the
color palette. Choose from the 16 colors available or click one of these
two buttons:
Custom Color Launches the Color dialog box where you can choose additional
colors from a color well of options.
None Disables fill color. Setting the fill color to None shows the display
background color.
Background Color
To determine what type of formatting is applicable for each symbol, refer to
the table of editable formatting attributes (page 81).
To configure background colors:
1. In Build mode, open a display, and click the symbol(s) whose
background color you want to change.
2. On the Symbol Formatting toolbar, click the Background Color
button . The background of the selected symbol changes.
The Background Color button is disabled if the selected symbol does
not support that property.
3. Click the arrow on the right side of the Background Color button to
display the color palette. Choose from the 16 colors available or click
one of these two buttons:
Custom Color Launches the Color dialog box where you can choose additional
colors from a color well of options.
None Disables background color. Setting the background color to None
shows the display background color.
