FactoryTalk Historian ProcessBook User Guide
142
Plot Time
You can set the time for each tag as it is highlighted in the Tags in Plot
box. If a Y tag is selected and its selection mechanism is not Recorded or
Interpolated, then these boxes are disabled.
Start The start time of the selected tag. The list includes *-1h (minus one
hour), *-4h, *-8h, *-1d, *-7d. The default is *-8h.
End The end time of the selected tag. The list includes *, *-1h, *-4h, *-
8h, *-1d, *-7d.
The default is * (current time).
Interval This field is enabled when the retrieval method is Interpolated. It
provides a sampling interval for data.
When you have completed configuring the fields on the General tab, click
the Display Format (page 143) tab.
Add a Data Set to an XYPlot
To add a data set to an XYPlot:
1. In Build mode, click Draw > XYPlot, or on the Drawing toolbar,
click .
2. Drag a rectangle on the display to create the boundaries.
3. Release the mouse button. The Define XYPlot dialog box appears
with the General tab open.
4. Click the arrow next to the Tag Search button.
5. Select ODBC or PI calculation to see the corresponding Dataset
Details or PI Calculation Data configuration dialog box.
6. When you have completed the configuration, click OK. The data set
name appears in the Tags in Plot box.
7. In the Define XYPlot dialog box, click OK to see the plot.
