Layout tab, E 115) – Rockwell Automation FactoryTalk Historian SE ProcessBook 3.2 User Guide User Manual
Page 133

5
●
Visualize Data with Symbols
●
●
●
●
●
115
Element Format group box - select formatting options for the selected plot
element. Your choices are reflected in the sample trend at the bottom of the
dialog box.
Layout Tab
The plot arrangement in a multi-plot trend is established by setting up the
number of rows and columns of plots in the Layout tab.
The Layout tab only appears when you initially create a trend (page 104).
Once the layout is set, you cannot revise it because the plots are no longer
associated when the symbol is created. However, individual plots can be moved on
the display in Build mode.
To revise the proposed plot arrangement matrix:
